Product Advantages: Self-developed high-performance motherboard: It can work continuously for 24 hours, no compatibility problem, and no error when printing. Automatic feathering: Print high-definition without brushing. Automatic flash spray: Effectively prevent plugging, one-key cleaning, and easier maintenance. Faster printing: The upgrade adopts the Epson 10th generation head, which is twice as fast as the traditional 1390A3 machine. Larger format printing: The platform size is 33*60cm, which can effectively print in the whole range, and the area is a full circle larger than the traditional 1390A3 machine. Double nozzle white color varnish at the same time: Both flat and cylindrical products can be printed. The highest printing height is 3-5MM. Ink processing system: Automatic ink circulation + stirring (to prevent white ink from settling), adding liquid level sensor, ink shortage indicator light and alarm system. Dual UV lamp configuration and adjustable intensity: Equipped with two UV lamps, drying is faster and firmer, and users can adjust the intensity of UV lamps according to different printing products.
Process advantages: | ||||||
1. Wide range of application:It can print mobile phone cases, decorative materials, glass, ceramic tiles,handicrafts, advertisements, toys, shoe materials, PVC, wood, etc. Almost all flat products and cylindrical products can be printed. | ||||||
2. Good color fastness: Abrasion-resistant, scratch-resistant, and blister-resistant, it will not change color after being exposed to wind, rain, and sun for a long time, and can pass the 100-grid test. | ||||||
3. Fine picture quality:The picture quality is exquisite, ultra-high precision, no wire drawing, no burrs, and the varnish has a more three-dimensional effect. | ||||||
4. Relief printing:Immediately print and dry, embossed effect can be printed, with obvious hand feeling, and the printed embossed 3D effect has strong visual impact. | ||||||
5. Simple operation:The operation is simple, and the finished product can be printed out at one time, without tedious operations such as plate making. |
Technical Parameters | ||||||
Model | A3+3360UV(CH05) | |||||
Printhead model | Epson tenth generation (TX800)optional | |||||
Printer size | 93*86*61cm | |||||
Effective printing area | 33*60cm | |||||
Printing speed | 6pass/8pass/16pass | |||||
Highest printing accuracy | 1440*2880dpi (with intelligent ink drop conversion technology) (resolution is inversely proportional to printing time) | |||||
Media thickness | 0-20CM | |||||
Number of printhead | 2 | |||||
Ink color | CMYK+white ink(WW)+Varnish | |||||
Ink Characteristics | UV ink | |||||
Ink cartridge | continuous ink supply/capacity 250ml | |||||
Drying system | UV_LED to solidify | |||||
Receive file type | TIFF(RGB&CMYK), BMP, PDF, EPS, JPGE, etc. | |||||
Power requirements | AC 220-240V,50/60Hz | |||||
Operating environment | Temperature 10-35C, Humidity 20-80RH | |||||
Operating system | Windows 10/8/7/Vista/XP Mac OS X 10.5.8or above | |||||
Power | 200W | |||||
UV cooling system | air cooled | |||||
Operation method | Smart integrated touch screen | |||||
Warranty period | 2 years warranty for the whole machine except consumables | |||||
Package Size | ||||||
Printer size | L 93cm* W 86cm*H 61cm | |||||
Package Size | L 115cm*W 95cm*H 80cm | |||||
Net weight | 100kg | |||||
Gross weight | 125kg | |||||
Package | Wooden packing |
