Product Advantages: 1. Self-developed high-performance motherboard: It can work continuously for 24 hours, no compatibility problem, and no error when printing. 2. Automatic feathering: Print high-definition without brushing. 3. Automatic flash spray: Effectively prevent plugging, one-key cleaning, and easier maintenance. 4. Faster printing: The upgrade adopts the Epson 10th generation head, which is twice as fast as the traditional 1390A3 machine. 5. Larger format printing: The platform size is 30*50cm, which can effectively print in the whole range, and the area is a full circle larger than the traditional 1390A3 machine. 6. Printing method: White color printing, both flat and cylindrical products can be printed. 7. Ink processing system: Automatic ink circulation + stirring (to prevent white ink from settling), adding liquid level sensor, ink shortage indicator light and alarm system.
| Process advantages: | ||||||
| 1. Wide range of application:It can print mobile phone cases, decorative materials, glass, ceramic tiles,handicrafts, advertisements, toys, shoe materials, PVC, wood, etc. Almost all flat products and cylindrical products can be printed. | ||||||
| 2. Good color fastness:Abrasion-resistant, scratch-resistant, and blister-resistant, it will not change color after being exposed to wind, rain, and sun for a long time, and can pass the 100-grid test | ||||||
| 3. Fine picture quality: Exquisite picture quality, ultra-high precision, no wire drawing, no burrs. | ||||||
| 4. Relief printing:Immediately print and dry, embossed effect can be printed, with obvious hand feeling, and the printed embossed 3D effect has strong visual impact. | ||||||
| 5. Simple operation:The operation is simple, and the finished product can be printed out at one time, without tedious operations such as plate making. |
| Technical Parameters | ||||||
| Model | A3+3050UV(CH04) | |||||
| Printhead model | Epson tenth generation （TX800）optional | |||||
| Printer size | 73*77*56cm | |||||
| Effective printing area | 30*50cm | |||||
| Printing speed | 6pass/8pass/16pass | |||||
| Highest printing accuracy | 1440*2880dpi (with intelligent ink drop conversion technology) (resolution is inversely proportional to printing time) | |||||
| Media thickness | 0-20CM | |||||
| Number of printhead | 1 | |||||
| Ink color | CMYK+white ink(WW) | |||||
| Ink Characteristics | UV ink | |||||
| Ink cartridge | continuous ink supply/capacity250ml | |||||
| Drying system | UV_LED to solidify | |||||
| Receive file type | TIFF(RGB&CMYK), BMP, PDF, EPS, JPGE, etc. | |||||
| Power requirements | AC 220-240V,50/60Hz | |||||
| Operating environment | Temperature 10-35C, Humidity 20-80RH | |||||
| Operating system | Windows 10/8/7/Vista/XP Mac OS X 10.5.8or above | |||||
| Power | 200W | |||||
| UV cooling system | air cooled | |||||
| Operation method | Smart integrated touch screen | |||||
| Warranty period | 2 years except consumables | |||||
| Package Size | ||||||
| Printer size | L 73cm * W 77cm * H 56cm | |||||
| Package Size | L 85cm * W 85cm* H 80cm | |||||
| Net weight | 65kg | |||||
| Gross weight | 95kg | |||||
| Package | Wooden packing | |||||
